Description
EC 9 -11 220V 60HZ TRAT
| Lamp | Ballast | Electrical | Thermal | Physical | |||||||||||||||
| Wattage | Voltage | Current | Length | Type | Article Number | Loss Hot | Input Power | Lamp Current | Lamp Start Current | Circuit | Line Current | Line Start Current | Capacitor | Normal/Abnormal | Stack | Figure | Length | Mtg Centres | Weight |
| W | V | mA | mm | W | W | mA | mA | cos ø | mA@0.9PF | mA@0.9PF | μF0.9PF | Δt | mm | mm | mm | kg | |||
| 220 V 60 Hz – EC energy control ballasts | |||||||||||||||||||
| Compact Lamps | |||||||||||||||||||
| 5 | 35 | 180 | TC-S | EC9 | 89000137 | 5.1 | 10.5 | 180 | 190 | 0.27 | 53 | 59 | 2 | 55/75 | 27 | 2 | 84.5 | 76 | 0.33 |
| 7 | 47 | 175 | TC-S | EC9 | 89000137 | 5 | 12.1 | 175 | 190 | 0.31 | 61 | 79 | 2 | 55/75 | 27 | 2 | 84.5 | 76 | 0.33 |
| 9 | 60 | 170 | TC-S | EC9 | 89000137 | 4.7 | 13.4 | 165 | 190 | 0.37 | 68 | 82 | 1.5 | 55/75 | 27 | 2 | 84.5 | 76 | 0.33 |
| 11 | 91 | 155 | TC-S | EC9 | 89000137 | 4.4 | 16.2 | 155 | 190 | 0.48 | 82 | 105 | 1.5 | 55/75 | 27 | 2 | 84.5 | 76 | 0.33 |
